1. 3M VHB 5925
3M 5925 VHB Foam Tape | Supply,Die cut
3MREF · 57
3M 57

3M VHB 5925

3m 5925 VHB tape. This is a Black, 0.6mm thickness modified acrylic adhesive with a very coordinated foam core. This tape can be used instead of mechanical fasteners or liquid adhesives and is specially designed for applications with thin bo

Thickness
0.6MM
Color
Black
Category
3M VHB TAPE
01 / TechnicalParameters

Spec overview

Values below are nominal with common converting forms. Actual tolerance, peel, and temperature performance vary with substrate, surface energy, and coat weight—confirm under your conditions before volume.

Brand / series3M
Category3M VHB TAPE
Nominal thickness0.6MM
ColorBlack
SizeCustomizable
AdhesionLook up in TDS
NotesFor more details, please refer to TDS. Support raw material supply and die-cutting customization.
ConvertingDie cutting · blanking · slitting
Inspection100% inspection / AQL sampling
Trade termsFOB · CNF · CIF · DDP
Supply formFull rolls · slit rolls · die-cut parts
3m 5925 VHB tape. This is a Black, 0.6mm thickness modified acrylic adhesive with a very coordinated foam core. This tape can be used instead of mechanical fasteners or liquid adhesives and is specially designed for applications with thin bonding lines. The fast and easy-to-use permanent bonding method provides high strength and long-term durability.
02 / Features

Why use it

Foam carriers aren't about "sticking harder"—they combine fastening, sealing, and cushioning in one step, replacing screws and clips.

  • 3m 5925 VHB Tape provides a fast, easy-to-use permanent bonding solution with high strength and long-term durability.
  • Can replace mechanical fasteners or liquid adhesives.
  • Black, 0.6mm thickness, modified acrylic adhesive, very suitable for acrylic foam core adhesive for all kinds of substrates.
  • Create permanent seals that can be waterproof, moistureproof, etc.
  • The use of pressure-sensitive adhesive when in contact can provide immediate operating strength.
  • Allow thinner, lighter weight and different materials
  • 03 / Applications

    Where it's commonly used

    Depending on carrier and adhesion, these materials show up in enclosure cushioning, panel sealing, interior bonding, and temporary hold. Confirm for your actual conditions.

  • Decorative material and trim
  • Nameplates and logos
  • Electronic displays
  • Panel to frame
  • Stiffener to panel
  • Other notes

    We have professional die-cutting equipment to provide customers with customized die-cutting services.
    04 / OptionalConverting

    What we can make from a full roll

    Buy full rolls and cut yourself, or take finished parts—both work. Finished parts are tooled to print; lead time includes the die and first-article approval.

    Die-cut forming

    Irregular contours, inner holes, and nested arrays—from CAD drawings or samples.

    FLATBED / ROTARY

    SlittingRewind

    Slit full rolls to the width you need; narrow rolls go straight to the laminating line.

    SLITTING

    LaminatingRelease liner

    Change release paper or film to match how the next process peels.

    LAMINATING

    Carrier tapePackaging

    Small parts on carrier tape / reels—ready for pick-and-place and automated assembly.

    SPOOLING

    Full rolls, or finished parts?
    We'll quote both.

    Send drawings or usage volume—we'll reply with a material plan, converting method, lead time, and price. Alternate-grade comparisons available on request.

    → Quote this grade
